TI 德州儀器可編程變量增益放大器 (PGA/VGA)

發布時間：2021-04-02 17:04:48 瀏覽：2443

TI德州儀器公司提供多種多樣可變性和可編程增益放大器，可增強電源電路的動態范圍，實時監控調整數據信號幅度。TI德州儀器的產品系列提供業界技術領先的零漂、高精度解決方案，工作頻率范圍從直流到4.5ghz，增益范圍更是高達1000V/v。

深圳市立維創展科技有限公司，專注于TI 德州儀器品牌高端可出口產品系列新品產品，并備有現貨庫存，可當天發貨。

詳情了解TI德州儀器請點擊：/brand/57.html

或聯系我們的銷售工程師： 0755- 83642657 QQ ： 2295048674

TI 德州儀器.jpg

Part number	PGA/VGA	Number of channels (#)	BW @ Acl (MHz)	Vs (Max) (V)	Vs (Min) (V)	Slew rate (Typ) (V/us)	Acl, min spec gain (V/V)	Gain (Max) (dB)	Operating temperature range (C)
LMH2832	VGA	2	1100	5.25	4.75	---	0.35	30	-40 to 85
THS7530-Q1	VGA	1	300	5.5	4.5	1250	3.8	46.5	-40 to 125
LMH6401	VGA	1	4500	5	4	18200	0.5	26	-40 to 85
PGA309-HT	PGA	2	---	5	2.7	0.5	---	128	-55 to 150
PGA281	PGA	1	6	36	10	1	0.125	42	-40 to 125
LMH6523	VGA	4	1400	5.25	4.75	---	0.5	25.74	-40 to 85
VCA5807	VGA	8	200	5.5	3.15	---	1	54	-40 to 85
LMH6882	VGA	2	2400	5.25	4.75	6000	2	26	-40 to 85
LMH6881	VGA	1	2400	5.25	4.75	6000	2	26	-40 to 85
LMH6522	VGA	4	1400	5.25	4.75	---	0.61	25.74	-40 to 85
LMH6521	VGA	2	1400	5.25	4.75	---	0.53	26	-40 to 85
THS770012	PGA	1	900	5	4.75	3400	4	13.7	-40 to 85
LMP7312	---	1	1.2	---	---	1.4	0.096	6	-40 to 125
LMH6517	VGA	2	1200	5.25	4.5	5000	0.33	22	-40 to 85
PGA870	VGA	1	650	5.25	4.75	2900	0.27	20	-40 to 85
PGA280	PGA	4	6	36	10	1	0.125	42	-40 to 125
LMH6518	VGA	1	900	5.25	4.75	760	0.87	38.8	-40 to 85
PGA117	PGA	10	10	5.5	2.2	3	1	46	-40 to 125
PGA116	PGA	10	10	5.5	2.2	3	1	46	-40 to 125
PGA308	PGA	2	---	5.5	2.7	0.6	---	---	-40 to 125
PGA113	PGA	2	10	5.5	2.2	3	1	42	-40 to 125
PGA112	PGA	2	10	5.5	2.2	3	1	42	-40 to 125
VCA8500	VGA	8	55	3.47	3.14	---	10	51	-40 to 85
LMH6514	VGA	1	600	5.25	4	1600	0.25	30	-40 to 85
VCA821	VGA	1	710	12	7	2500	2	40	-40 to 85
VCA824	VGA	1	710	12	8	2500	2	40	-40 to 85
VCA820	VGA	1	150	12	7	1700	10	40	-40 to 85
VCA822	VGA	1	150	12	7	1700	10	40	-40 to 85
LMH6505	VGA	1	150	12	7	1500	1	40	-40 to 85
VCA2615	VGA	2	42	5.25	4.75	100	2.8	61	-40 to 85
VCA2617	VGA	2	50	5.25	4.75	100	0.32	48	-40 to 85
LMH6515	VGA	1	600	5.25	4	---	0.45	24.2	-40 to 85
VCA8617	VGA	8	100	3.15	2.85	300	1.8	58	-40 to 85
VCA810	VGA	1	35	10	10	350	0.01	40	-40 to 85
PGA309	PGA	2	---	5	2.7	0.5	---	---	-40 to 125
LMH6502	VGA	1	130	12	5	1800	1	40	-40 to 85
LMH6503	VGA	1	135	12	5	1800	1	40	-40 to 85
THS7530	VGA	1	300	5.5	4.5	1250	3.8	46.5	-40 to 85
VCA2612	VGA	2	40	5.25	4.75	300	8	53	-40 to 85
THS7001	VGA	1	100	32	9	85	0.08	20	-40 to 85, 0 to 70
THS7002	VGA	2	100	32	9	85	0.08	20	-40 to 85, 0 to 70
PGA103	PGA	1	1.5	36	9	9	1	40	-40 to 85
PGA205	PGA	1	1	36	9	0.3	1	18	-40 to 85
PGA204	PGA	1	1	36	9	0.3	1	60	-40 to 85
PGA203	PGA	1	1	36	12	15	1	18	-25 to 85
PGA202	PGA	1	1	36	12	15	1	60	-25 to 85
LM359	---	2	400	22	5	60	---	100	0 to 70
